Model: YF-A2M-25.6V-100W

Product Specifications

Material Die-casting Aluminum+Aluminum
Protection Level IP66
Light Efficiency 200 lm/W
Lifetime 100000 hrs
Light Source smd5050
CCT 2700k_6500k
Beam Angle 150°*60°
MOQ 100 pcs
Driver Brand No Driver
Sensor Yes
Warranty 5Years
Installation Standing Pole Mounted
WhatsApp

100W Modular All-In-One Solar Street Light

Key Features

1.All-in-one design with 100W PERC panel + 12.8V/30Ah LiFePO4 battery, no wiring needed.

2.Dual light/motion sensors auto-adjust brightness (100% when active, 30% standby), saving 60% energy.

3.5-day operation in cloudy weather, -30°C cold start, 10+ years lifespan.

4.Pre-assembled 6M pole, installed in 1 hour with wall/pole mounting options.

Light on Time: full light more than 15 hours, energy saving mode lights up for more than 48 hours.

Charging Time: 6-8h

Working Temperature: -30℃-+60℃

LED Brand: Philips

Installation Height: 4-6 meters

Option Power:100W/150W/200W/250W

Application

1.Grid-free lighting for urban/rural roads, cutting public energy costs.

2.Smart lighting for campuses and industrial parks with enhanced security.

3.Off-grid power for remote islands, pastures, and mountainous areas.

4.Emergency lighting for disaster relief with rapid deployment.

Advantages

1.The lighting angle of the modules can be adjusted remotely on one press.

2.Zero Maintenance: No electricity cost, 10-year battery lifespan.

3.Military-Grade Durability: Wind-resistant (Beaufort 12), anti-corrosion.

4.Iot Integration: Optional 4G remote monitoring for real-time control.

Power Solar Panel/Dimension Battery
100 W 18V60W/888*394*4mm 12.8V30AH
150 W 18V80W/1158*394*4mm 12.8V40AH
200W 18V100W/1358*394*4mm 12.8V50AH
250 W 18V120W/1708*394*4 mm 12.8V60AH
Solar Panel 60W
Battery Capacity 12.8V30AH
Luminous Flux 5800LM
Size 950*420*240
